High Quality Cassava Starch Drying Machiney & Potato Starch Flash
Dyer
Description of flash dryer :
Therefore material is crushed by centrifugal, shearing, impacting
and friction effect. It strengthens the heat exchanging process. In
the bottom of drying chamber, big and damp granules are crushed by
stirring device, the particles with low moisture content and small
size are lifted by rotary air stream, and be further dried. Gas and
solid two phases rotary flow, inertia of solid phase is bigger than
gas phase, the relative velocity between gas phase and solid phase
is high, heat exchanging efficiency is strengthened, so the drying
intensity of this machine is high.
Type of flash dryer :
| Type | Capacity | Material |
| VF-2 | 2t/h dry starch | SS304 |
| VF-4 | 4t/h dry starch | SS304 |
| VF-6 | 6t/h dry starch | SS304 |
| VF-8 | 8t/h dry starch | SS304 |
| VF10 | 10t/h dry starch | SS304
|
Working Principle:
The flash dryer consists of dry main engine, feeder, heat source
device (hot air furnace or steam), air filter, air blower,
cyclone separator, bag filter, and induced draft fan. The hot air
tangentially enters the bottom of the dryer and is driven by the
agitator to form a powerful rotating wind field. The paste material
enters the dryer by the screw feeder. Under the strong action of
the high-speed rotating stirring paddle, the material is dispersed
under the action of impact, friction and shearing force, the block
material is rapidly pulverized, and it is fully contacted with hot
air and heated ,and dry. The dehydrated dry material rises with the
hot gas flow, and the classification ring intercepts the large
particles. The small particles are discharged from the center of
the ring to the outside of the dryer, and are recovered by the
cyclone separator and the dust collector. The dry material is not
dried or the bulk material is subjected to centrifugal force , fell
to the bottom and was crushed and dried.
FAQ:
Q1: Is your company a factory or trading company?
A: Our company is a factory in Henan Province ,with export license
and we have done export business over 20 years professionally.
Q2. What is your main business?
A: ZY is devoted to starch processing machine. The machine of starch processing line , such as : cassava starch line , cassava flour
line , potato starch line , sweet potato line , wheat starch ,sago
line and garri line
Q3: Where is your factory located? How can I visit there?
A: Our add: Jianshe Road , Zhengzhou City , Henan Province , China.
Warmly welcome to visit us!
Q4: Are your products can be assured ?
A: Our machines are all passed ISO9001:2001 and have CE certificate
by SGS, TUV.
